912 Series Carburetor - Single Parts

B – Loctite 243

a – For cylinder 2 and 1/3;
b – For cylinder 1 and 2/4;
c – Carburetor housing not available as spare part. Use carburetor assembly,
d – Refer to service instruction SI-03-1998 current issue,
e – With clearance for O-ring (use only together with O-ring pos. 18 (P/N 950430);
f – For airbox P/N 867758, P/N 867756; See SB-912-044;
g – See SI-912-012, SI-914-014;
h – Package including two floats;
i – Special jetting according to instructions of the manufacturer;
j – Contain parts requirement for 2 carburetors;
k – Overhaul kit for 1 carburetor
