Reduction Gearbox "E": 2.62, 3.00, 3.47 or 4.00

A – Loctite 221
C – Loctite 648
E – Loctite Anti-Seize
H – Loctite 603
I – Lithium-Base Grease
Q – 732 RTV

AR – As required

a – Replace layshift gear 55 T and pinion shaft 21 T only together;
b – Replace layshift gear 57 T and pinion shaft 19 T only together;
c – Replace layshift gear 59 T and pinion shaft 17 T only together;
d – Replace layshift gear 60 T and pinion shaft 15 T only together;
e – Attention: Left handed thread;
f – Coupling-flange Part No. 958 971 and sealing ring Part No. 950 084 has to be used as a set;
h – Gear set and splitted cone sleeve must be used together;
|| – NOTE: Included starter relay;
See also SI-2ST-007
