Bing Double-Float Carburetor 36 MM, Model 54

447 UL – 29.5 kW
503 UL – 34 kW
582 UL

a – Base carburetor for air-cooled engines with bowden cable choke. NOTICE carburetor without calibration. From engine S/N 447 UL: 3,940.675, 503 UL: 4,795.201;
b – Base carburetor for liquid cooled engines with bowden cable choke. NOTICE carburetor without calibration; From engine S/N 582 UL Mod. 90: 4,656.088, 582 UL mod. 99: starting with serial production;
c – Carburetor housing, not available as spare part, use carburetor assy.;
d – Jet-needle, see carburetor calibration sheet;
e – Idle-jet, see carburetor calibration sheet;
f – Needle-jet, see carburetor calibration sheet;
g – Main-jet, see carburetor calibration sheet;
h – Only necessary on high altitude compensation kit (not available anymore)
