912 & 914 Series Magneto-Generator, Pick-Up, Rectifier Regulator

B – Loctite 243
I – Lithium-Base Grease
O – Engine Oil

a – Stator retrofit kits: 912 UL: S/N 3,792.501 up to 3,792.55 Set D P/N 888716, S/N 4,005.300 up to 4,152.111 Set E P/N 888718, S/N 3,792.556 up to 4,005.299, Set C P/N 888714; S/N 4,152.112 up to 4,403.282 Set B P/N 888712; 912 ULS: S/N 4,425.001 up to 4,425.029 Set A P/N 888710; 914 UL: S/N 4,417.503 up to 4,417.783 Set B S/N 888712;
b – With modified trigger, instead of 4° before top dead center --> -3° after top dead center;
c – SI-912-013 / SI-914-016 standardization of the ignition unit;
d – Trigger coil kit with elongated hole for adjustment and 6-pole connector incl. 7 Stk. P/N 827800;
e – 4-pole connector and trigger coils without alignment incl. 7 Stk. P/N 827800. Replaced trigger coil kit P/N 965177;
f – Trigger coils for rev. counter to P/N 965176 and P/N 965179;
g – At all trigger coils with longhole
