912 & 914 Double Ignition Coil Assy., SMD-Electric Module

B – Loctite 243
I - Lithium-Base Grease
AG – Silicon Heat Compound

a – Sold by the meter (39");
e – Not necessary at intake manifold P/N 867688;
f – Introduced as S/N 04.0388 with altered insulation only for spare parts;
g – Not suitable for crankcase P/N 886354, P/N 886358 and older;
h – At crankcase P/N 888364 or newer crankcase;
i – Not suitable for intake manifold P/N 867688;
j – Necessary at version with ring mount;
k – Sold by the meter (39");
l – Use P/N 842742 and 953390 only together;
m – SI-912-013 / SI-914-016 current issue. See Maintenance Manual Heavy of the respective engine type, current issue. From engine 912 UL S/N 4,406.291, 912 ULS S/N 5,643.680, 914 UL 4,418.712;
n - In a roll, silicone hose 120 mm;
o – SI-912-020 / SI-914-022 current issue;
p – 1x lock washer A6 P/N 945751 is not needed after production-year 2010 on position between the bracket 2 P/N 851267 and the hex nut M6
