912 & 914 Crankcase from S/N 14.4000

B – Loctite 243
C – Loctite 648
L – Klueber Isoflex Topas Nb5051
O – Engine Oil
P – Loctite 5910

a – Only for model 2 and 4;
b – Tolerance group "C" 1.820 - 1.829 mm;
c – Tolerance group "C" 1.830 - 1.839 mm;
d – See Overhaul Manual of the respective engine type, current issue

In stock

SKU

912-914Crankcase3

Grouped product items
Fig No.	SKU	Product Name	Availability	Price	Qty
2	842-650	F/ HELI-COIL THRD INSERT M8	Out of Stock	$12.56	Out of stock
3	924-451	F/ OIL TUBE	Out of Stock	$30.67	Out of stock
4	929-951	F/ DOWEL 10,8X25	Out of Stock	$21.17	Out of stock
5	929-845	F/ PIN D8X20	Out of Stock	$5.15	Out of stock
6	840-191	F/ STUD M8 X 105	Out of Stock	$20.10	Out of stock
7	944-222	BLINDING SHIM	In Stock	$20.63
8	430-061	O-RING 26.7 X 1.8	In Stock	$1.12
9	850-902	O-RING 9,2-2-N FPM	In Stock	$0.87
10	944-131	WASHER 8 MM	In Stock	$1.14
12	840-092	F/ STUD M8x1x153	Out of Stock	$27.71	Out of stock
13	840-102	F/ STUD M8x1x163	Out of Stock	$35.87	Out of stock
14	940-071	HEX SCREW M8 X 45	In Stock	$9.15
15	440-406	F/ M8 X 65 COLLAR HEX SCREW	Out of Stock	$24.67	Out of stock
16, 31	842-476	COLLAR CAP NUT M8	In Stock	$55.61
18	840-887	ALLEN SCREW M6X30 DIN 912	In Stock	$1.46
19	227-280	TAPERED THRUST WASHER	In Stock	$3.44
21	941-487	ALLEN SCREW M10X110 DIN91	In Stock	$7.47
21	941-557	F/ ALLEN SCREW M10X150 DIN91	Out of Stock	$12.77	Out of stock
23	927-410	WASHER 10,5	In Stock	$0.52
26	831-929	O RING 5 X 2	In Stock	$1.12
27	840-141	STUD M8 X 186	In Stock	$18.48
28	840-171	STUD M8 X 200	In Stock	$18.99
29	431-570	O-RING 10,82X1.78-N, STUD BASE	In Stock	$0.45
32	842-860	F/ COLLAR NUT M8x1	Out of Stock	$36.89	Out of stock
33	840-132	F/ STUD M8x1x139	Out of Stock	$31.20	Out of stock
35	950-141	GASKET RING A8 X 13	In Stock	$0.51
37	440-107	ALLEN SCREW M8X50 DIN912	In Stock	$3.17
39	926-400	WASHER 8,4/15/0,5	In Stock	$4.57
39	926-401	WASHER 8,4/15/1	In Stock	$4.89
39	926-402	WASHER 8,4/15/1,5	In Stock	$5.15
40	881-120	CRANKBOLT KIT, FROM 06.0010 TO 14.XXXX	In Stock	$1,042.74

Details

912 & 914 Crankcase from S/N 14.4000

More Information

More Information
Udf EUC	No
Udf Special Order	No

912 & 914 Crankcase S/N 06.0010 up to 14.4000

912 & 914 Crankcase from S/N 14.4000
