582 UL MOD. 99 Crankcase, Rotary Valve Drive & Water Pump

A – Loctite 221
B – Loctite 243
C – Loctite 648
D – Loctite 574
O – Engine Oil

a – 582 UL DCDI mod. 99 rotary valve for configuration with rotary seal;
b – 582 UL DCDI mod. 99 the circlip must be positioned at the inner groove only;
e – Crankcase including rotary valve drive, configuration with rotary seal model 99

In stock

SKU

582ULCrankcase99

Grouped product items
Fig No.	SKU	Product Name	Availability	Price	Qty
1-12	888-471	F/ CRANKCASE ASSY	Out of Stock	$1,020.48	Out of stock
1-29, 42	888-476	F/ CRANKCASE ASSY 582	Out of Stock	$1,555.02	Out of stock
9, 37	230-415	GASKET RING A6X10	In Stock	$0.27
10	240-771	HEX SCREW M6 X 10	In Stock	$0.52
11	922-242	ANGULAR TUBE 1/4-18 NPT	In Stock	$39.86
12	940-190	STUD M10X29/20	In Stock	$4.31
15	932-797	BALL BEAR. 6201-Z 12-32-1	Out of Stock	$20.91	Out of stock
16	245-420	RETAINING RING 32 X 1.2	In Stock	$1.71
17	850-711	OIL SEAL 10X30X8	In Stock	$5.49
18	837-250	ROTARY SHAFT 582/99	In Stock	$463.32
19	930-580	OIL SEAL 20X40X7	In Stock	$12.49
20	932-032	BALL BEARING 6203TVHC3	In Stock	$35.01
21	227-439	SHIM 17.2/ 32.5/ 1.5	In Stock	$8.15
22	845-450	RETAINING RING, 17X1	In Stock	$0.59
23	847-282	D/ SPACER	In Stock	$44.52
25	831-500	O-RING 14-3 (532)	Out of Stock	$0.21	Out of stock
26	935-736	ROTARY VALVE GEAR 14T	In Stock	$76.94
27	938-810	COMPRESSION SPRING 25,1MM	In Stock	$5.43
28	827-430	SPRING HOLDING CUP	In Stock	$13.56
29	845-160	CIRCLIP 12	In Stock	$1.14
30	227-945	WASHER 8.1/15/0.5	Out of Stock	$0.87	Out of stock
31	227-155	FRICTION WASHER	Out of Stock	$27.27	Out of stock
32	922-036	IMPELLER	Out of Stock	$5.27	Out of stock
33	244-211	WASHER 6,4 All EXCEPT 277	In Stock	$0.27
34	842-042	LOCK NUT M6	In Stock	$0.59
35	831-616	IMPELLER GASKET	In Stock	$5.82
36	922-503	WATER PUMP HOUSING	In Stock	$554.69
39	940-551	HOSE NIPPLE M6	In Stock	$56.49
42	945-880	RETAINING RING 40X1,75	In Stock	$2.85
43	924-504	ROTARY VALVE 132 DEGREE	In Stock	$37.05
49	851-111	CABLE CLAMP 8/M5	In Stock	$62.07
50	851-113	CLAMP 18/M5	In Stock	$28.50
51	650-370	ROTARY SEAL	In Stock	$39.04
52	897-501	RED WARNING LABEL	In Stock	$6.58

Details

582 UL MOD. 99 Crankcase, Rotary Valve Drive & Water Pump
