582 UL MOD. 90 Cylinder, Cylinder Head

A – Loctite 221
B – Loctite 243
C – Loctite 648
D – Loctite 574
J – Molykote 44 Medium

a – Red 76,00 - 76,01mm, Green 76,01 - 76,02mm;
b – For configuration without 2-piece radiator;
c – For configuration with 2-piece radiator

In stock

SKU

582ULCylinder90

Grouped product items
Fig No.	SKU	Product Name	Availability	Price
1	850-775	Cylinder Base Gasket 0.5mm (Rotax 532 Dual)	In Stock	$26.18
2	913-448	Cylinder with Sleeve, 2-Stroke	In Stock	$1,424.83
4	850-040	Head Gasket Rubber Ring (Rotax 532/582) 152,5x2,5x5	In Stock	$10.12
5	850-540	O-Ring 83X2 (Rotax 532)	In Stock	$5.63
6	941-390	Stud M8x79	In Stock	$8.44
9	913-310	Cylinder Head	In Stock	$1,113.53
10	842-476	Collar Cap Nut M8	In Stock	$36.38
11	941-080	Stud M6x20/10	In Stock	$3.80
12	230-980	Rubber Gasket	In Stock	$5.78
13-14	222-014	582 Model 90 Thermostat with Gasket	In Stock	$134.07
13	230-800	582 Mod 90 Thermostat Gasket	In Stock	$3.23
16	922-025	Water Outlet Socket	In Stock	$18.81
17	922-061	Bent Outlet Socket	In Stock	$46.26
18	244-211	Washer 6.4 DIN 134	In Stock	$0.21
22	240-483	Plug Screw 1/8-27NPT	In Stock	$15.39
23	230-415	Gasket Ring A6x10 DIN 7603	In Stock	$0.18
25	940-551	Hose Nipple M6, 2-Stroke / Torque: 3 Nm / 26 in. lb.	In Stock	$50.65

582 UL MOD. 90 Cylinder, Cylinder Head

More Information
Udf EUC	No
Udf Special Order	No
