582 UL Mod. 90/99 Repair Tools

a – For cylinder;
b – For cylinder exhaust flange;
c – For rotary valve shaft;
d – For ball bearing, rotary valve shaft;
e – For oil seal rotary valve shaft (wihout oil pump), intake side;
f – For oil seal rotary valve shaft (with oil pump), intake side;
g – For inner oil seal rotary valve shaft, water pump side;
h – For outer oil seal rotary valve shaft, water pump side;
i – To press in the rotary seal;
j – For rotary valve timing;
k – To pull out the rotary seal - the inner steel bushing of the rotary seal has to be removed before demounting!;
l – For fitting of piston pin circlip;
m – For fitting of piston pin circlip (monohook circlip);
q – To press in the rotary seal 850942 with the insertion jig
