503 UL CDI Crankshaft, Piston – Provision 8

503 UL CDI Crankshaft, Piston – Provision 8

503 UL CDI Cylinder & Intake Manifold, Dual Carburetor Configuration

503 UL CDI Cylinder & Intake Manifold, Dual Carburetor Configuration

503 UL CDI Cylinder, Cylinder Head, Intake Manifold, Single Carburetor Configuration

b – For mixture lubrication;
c – For oil pump version

In stock

SKU

503ULCylinderSingle

Grouped product items
Fig No.	SKU	Product Name	Availability	Price	Qty
1	831-855	Cylinder Base Gasket 0.4mm (Rotax 277/503)	In Stock	$4.91
2	923-010-1	Cylinder with Sleeve Type A Red Dot, 503	In Stock	$769.31
2	923-010-2	Cylinder with Sleeve Type B Green Dot, 503	In Stock	$882.04
3	831-881	Head Gasket, 503	In Stock	$13.28
4	823-668	Cylinder Head, 2-Stroke	In Stock	$667.70
6	242-209	Hex Nut M8, 2-Stroke, 912/914	In Stock	$0.37
7	842-055	Distance Nut M8X37	In Stock	$48.15
8	831-866	Intake Gasket 1.0 MM (All Except Rotax 532/582)	In Stock	$4.22
11	940-616	Hex Screw M8X40	In Stock	$0.78
13	850-151	Rubber Ring 83x1.5x3.5, 2-Stroke	In Stock	$5.16
18	941-501	Hex Screw M6X30	In Stock	$1.24
19	860-060	Support Damper	In Stock	$3.45
20	860-096	Noise Damper, Short, 503	In Stock	$13.79
21	860-091	Noise Damper, Long, 2-Stroke	In Stock	$7.95
22	867-484	Carburetor Socket (Rotax 377-503)	In Stock	$31.00
23	951-510	Hose Clamp 52	In Stock	$12.38

503 UL CDI Cylinder, Cylinder Head, Intake Manifold, Single Carburetor Configuration
