447 UL CDI Magneto Generator 12V 170W, Electronic Box, Starting Pulley

A – Loctite 221
I – Lithium-Base Grease



a – For configuration free-air-cooled;
b – In a roll/Sold per meter (39");
c –  For magneto flywheel new version (with closed cage), Torx screw also valid for old version. At disassembly and reassembly of the screw, the thread has to be cleaned of the remaining coating and secure with Loctite 221. As an alternative a new screw can be used.

In stock
SKU
447ULMagneto
Grouped product items
Fig No. SKU Product Name Availability Price Qty
1 996-826 F/ TRIGGER WHEEL ASSY. In Stock
$406.17
2 996-849 STATOR, 582/99, 12W150 In Stock
$519.48
3 966-207 F/ STATOR PLATE In Stock
$76.51
6 641-521 TORX SCREW M5x16-T25K In Stock
$2.87
7-9 965-761 PICK-UP ASSY SHORT WIRE In Stock
$101.00
8 964-072 ISOLATION SHEATH In Stock
$0.45
12 945-759 LOCK WASHER 22 In Stock
$1.71
13 842-239 Hex Nut M22x1,5 (377, 447) In Stock
$7.89
14 980-486 V-BELT PULLEY In Stock
$75.41
15 852-412 F/ PULL START PULLEY 26.46MM ALL 503/447/377 Out of Stock
$53.54
Out of stock
16 845-310 LOCK WASHER VHZ 8 (377,44 In Stock
$4.57
17 841-520 ALLEN SCREW M8X12 (503) In Stock
$1.14
19 960-550 PROTECTION CAP In Stock
$1.52
20-21 965-153 IGNITION CABLE, PER METER In Stock
$19.27
18 966-467 ELECTRONIC BOX In Stock
$333.58
22 830-962 PROTECTION HOSE 12x16x40 In Stock
$11.25
24 244-211 WASHER 6,4 All EXCEPT 277 In Stock
$0.27
26 940-561 D/ SLOTTED HEX SCREW M6x20 In Stock
$0.63
27 897-055 BR8ES SPARK PLUG-SOLID CA In Stock
$2.94
29 966-060 SPIRAL HOSE & BAND PER METER In Stock
$35.06
30 860-962 CABLE GROMMET 24,5/11 In Stock
$3.32
447 UL CDI Magneto Generator 12V 170W, Electronic Box, Starting Pulley
