447 UL CDI Crankshaft, Piston

A – Loctite 221
E – Anti-Seize
I – Lithium-Base Grease
O – Engine Oil



a – With 2 rings, Standard;
b – With 2 rings, 1st Oversize;
c – With 2 rings, 2nd Oversize;
d – Standard Size;
e - 1st Oversize;
f – 2nd Oversize;
g – ATTENTION: Use only once

In stock
SKU
447ULCrankshaft
Grouped product items
Fig No. SKU Product Name Availability Price Qty
2 250-165 O-Ring 64x2 In Stock
$0.58
4 831-950 Crankshaft Oil Seal 35x72x7/8,5 In Stock
$12.48
5 246-055 Woodruff Key 3x3.7 DIN 6888 In Stock
$1.35
6-7 832-325 Cageless Needle Bearing 18X22X21,8 In Stock
$35.15
8 945-759 Lock Washer 22 In Stock
$1.14
9 842-239 Hex Nut M22x1,5 In Stock
$5.43
10-12 886-050-1 447 Standard Size Piston Assembly 67.45mm Red Dot In Stock
$286.47
11 915-960 Rectangular Ring 67.5 MM, 447 In Stock
$67.05
11 915-962 Rectangular Ring 68.0 MM In Stock
$74.24
12 915-845 Semi-Trapez Ring 67.5mm In Stock
$95.55
12 915-846 Semi-Trapez Ring 67.75mm In Stock
$101.05
12 915-847 Semi-Trapez Ring 68.0 DIA. In Stock
$101.05
13 916-136 Piston Pin 18x11x53.7, 447 & 582 In Stock
$19.19
14 945-735 Circlip 18 In Stock
$1.35
15 897-280 Cageless Label In Stock
$0.18
447 UL CDI Crankshaft, Piston
