2-Piece Radiator Set for Inverted Engine Installation, ROTAX 582 UL Mod. 90/99

A – Loctite 221
B – Loctite 243
Q – Silastic 732 RTV

AR – As required

a – Cooling surface 3,2 dm² (49,6 in²);
b – From engine S/N: 3,916.823;
c – Up to engine S/N: 4,916.822;
d – For evacuation of air, at installation of engine with spark plugs down;
e – Longer studs for 582 UL Mod. 90. Not used on 582-99;
f – Sold by the meter (39”)
